Lisa sterilizer

Fast. Easy to use. Secure traceability.

Sterilization with maximum speed and an excellent performance thanks to the patented Eco Dry technology and fast cycle, able to process unwrapped load in 15 minutes. Enjoy simple, userfriendly and legally protected sterilization processes due to its ease of use and secure traceability.

Discover Product

Lisa
Technical data

High performance sterilization
Making the difference

Long service intervals and internal components protected by
› Water separation system
› Dust filter
› Water quality sensor

Save energy with
› Automatic standby mode

Fast troubleshooting and reduced repair costs thanks to
› New automatic diagnostic cycles

In case of power failure, instruments can be easily retrieved from the chamber with the
› Battery-operated door opening tool
Your advantages at a glance:
- The Eco Dry technology adapts the cycle time automatically to the load weight
- Fast S-type cycle processes 0.6 kg of unwrapped instruments in 15 minutes
- User-friendly smart interface with help buttons and 3D animations for easy navigation and guided maintenance steps
- Built-in water separation system, dust filter and quality sensor
- Programmable cycle start
- Integrated automatic water filling valve
- Full traceability pack for legal protection
Eco Dry technology
for accelerated type B cycles* (*type B sterilization of average load of 2 kg in 30 minutes)

Fast cycle
for fast sterilization of unwrapped instruments in 15 minutes

Extended connectivity thanks to Ethernet port (LAN) or Wi-Fi kit (optional). W&H Med Steri App to control up to 4 sterilizers

Ease of use
thanks to smart user interface and user-friendly menu structure

Automatic water
filling
saves time and ensures maximum ergonomics

Smooth surface design for easy cleaning

Built-in USB
data logger
for digital cycle documentation and legal protection

Barcode label printer (optional)
for the extension of the documentation system by making the link »load – cycle – patient«

User authentication and load release option
for a complete and customized traceability system

Performance

The advanced patented Eco Dry technology adapts the drying time to the load mass. This reduces the cycle time, increases life span of your instruments and optimizes energy consumption.
- Time saving

  Time saving

  B-type cycles process and perfectly dry 2 kg of load in only 30 minutes.
- Extends service life

  Extends service life

  Automatic adjustment of the drying time depending on the load reduces the heat exposure time. This extends the service life of your instruments.
- Energy saving

  Energy saving

  The optimization of the drying time means reduced energy consumption. Making Lisa the »green solution«.
Sterilization in
record time
The S-type fast cycle guarantees a quick and efficient sterilization of 0.6 kg of unwrapped instruments in only 15 minutes.

Drying quality
is a must for keeping sterile conditions during load storage. Lisa ensures an excellent drying quality of the complete load.

Full traceability

Lisa offers a comprehensive traceability system customized to your needs. A wide range of features and options guarantees an automatic documented sterilization protocol without the need of paper handling, a dedicated computer or software.

High capacity data logger The high capacity USB drive automatically records the cycle reports for the entire life of Lisa.

Customized to your needs
Lisa traceability menu offers a wide range of options to customize your own traceability system to your exact needs.

User authentication Allows you to digitally record the user who loaded and unloaded the sterilizer. Users are identified by a secure PIN.

Load release confirmation
This option digitally records the user name and their confirmation of the successful sterilization and/or test cycle.

Easy and practical
Lisa enables you to select the number of labels to be printed by EliSafe either automatically or manually.

Convenient and economical
The Ethernet connection allows four Lisa sterilizers to share one LisaSafe label printer.
- Lisa mobile app

  Real time remote monitoring

  With Lisa Mobile App you are able to monitor up to 4 sterilizers with your smartphone or tablet in real time from any place within your practice.
- Additional backup

  Additional backup

  The cycle database is also saved in your smartphone or tablet. This guarantees you an extra backup and enables you to check any cycle report at any time.
- Barcode scanner

  Barcode scanner onboard

  Lisa Mobile App is able to retrieve cycle reports from a barcode label printed by LisaSafe. The barcode can be read with the smartphone camera.
- User management

  User management

  You are able to create and delete users and link pictures to them. The user list will be automatically updated on the sterilizer.
Ease of use

The Lisa colour touch screen with its user- friendly menu structure and intuitive icons has been selected and designed to make your daily work easier, faster and more efficient.
- Device control

  Device control

  The Lisa touch screen with clear menus offers a wide range of options to meet all your needs.
- Simple cycle selection

  Simple cycle selection

  As soon as Lisa is switched on, the home screen immediately displays the cycle selection.
- Intuitive navigation

  Intuitive navigation

  Four logic activity groups are displayed for swift and efficient navigation.
- Risk-free cycle selection

  Risk-free cycle selection

  The custom cycle selection feature allows you to select which cycles are displayed on the home screen.
- User guidance

  User guidance

  Instruction is available with the help button in order to assist you during navigation.
- Maintenance animations

  Maintenance animations

  A set of 3D animations shows you the main maintenance operations step by step. Makes operation easy and straightforward.
Ergonomics

The revised design is setting optimized hygiene and ergonomic standards in modern medical treatment.
- Easy filling

  Easy filling

  A high capacity integrated funnel prevents water splashes during the water ﬁlling process.
- Simple cleaning

  Simple cleaning

  Thanks to a smooth surface design with minimized gaps.
- High convenience

  High convenience

  An automatic water ﬁlling valve allows you to connect a demineralization system. Manual ﬁlling and draining are no longer required.
- Fits everywhere

  Fits everywhere

  With the modular front feet, Lisa can be installed on the narrowest benches.
- Practical design

  Practical design

  Lisa can be built into a cabinet thanks to the optimized internal air circulation.
- Effortless tank access

  Effortless tank access

  The tank cover can be easily removed without tools to clean the tanks.
Lisa sterilizer

supplied with reversible rack, 5 aluminium trays, drain tube, tray holder, USB drive, door opening tool, factory test

Lisa VA131-22
REF 19932121

Chamber size 22 l
200–240 V AC; 50/60 Hz; 10 A

Request Price
Download Area
Instructions for use

Instructions for Use Lisa

Maintenance Sheet
Lisa VA 131 2019

Downloads

Brochure Lisa

Collection brochure sterilizers
Videos & Tutorials
Coming soon
Service
Service

Disposal Guidelines

Lisa sterilization programs

Sterilization cycle:	B-Universal 134		B-Prion 134		B-Universal 121	Fast cycle
Temperature:	134 °C		134 °C		121 °C	134 °C
Holding time (minutes):	5' 30''		20’ 30’’		20’ 30’’	3’ 30’’
Total cycle duration (minutes) including complete drying:	Automatic from	Typical load	Automatic from	Typical load	Automatic from	Full load
	23’– 51’	33'	38’– 66’	49'	41’– 68’	15'
Max. load;	max. solid 6 kg/typical 2 kg/max. porous 2 kg					max. solid 0.6 kg
Max. containers load:	max. 9 kg				Not applicable
Test cycles:	Helix/Bowie Dick/Vacuum test

Items supplied with reversible rack, 5 aluminium trays, drain tube, tray holder, USB drive, door opening tool, factory test

Lisa sterilizer

Trade name:	Lisa
Type:	VA131-22
Chamber size:	22 l
Power supply:	200–240 V AC; 50/60 Hz; 10 A
Power consumption:	2.0 - 2.4 kW
Overall dimension (width × height × depth):	465 × 451 × 635 mm
Weight:	51.7 kg
Main / Used water tanks:	4/3.5 l
Working range:	6 to 12 cycles
Usable space (w × h × d):	195 × 195 × 390 mm¹
Connection types:	1 Ethernet port, 3 USB ports, 1 serial port, integrated automatic water filling valve

^{(1) Usable space is referred to standard rack configuration.}

Lisa sterilizers were designed, certified and validated with the most stringent regulations, directives and standards:
N°2017/745	Medical Device Regulation	IEC 61010-1	Safety requirements
2012/19/EU	Waste Electrical and Electronic Equipment	IEC 61010-2-040	Specific requirements for steam sterilizer
EN 2014/68/EU	Pressure Equipment Directive	IEC 61770	Electric appliances connected to the water mains
IEC 61326-1	Electromagnetic compatibility	EN 13060	Small steam sterilizers
› The sterilizer can be validated according to EN ISO 17665-1
